HABROK 4K HH35L 2.0 Multispectral Binoculars, HIKMICRO

HABROK 4K HH35L 2.0 Multispectral Binoculars by HIKMICRO

The HABROK 4K HH35L 2.0 by HIKMICRO is a multispectral binocular system for daytime, night-time, and thermal observation. It combines a thermal imaging module, 4K digital optics, an interchangeable infrared illuminator, and a laser rangefinder, making it particularly suitable for hunting and wildlife observation in various lighting and weather conditions.

The thermal imaging module uses an uncooled VOx sensor with a resolution of 384 × 288 px, a 12 μm pixel pitch, and a sensitivity of < 15 mK. Combined with a 35 mm F1.0 lens, it provides a detection range of up to 1,800 m. It offers 4× optical magnification, 5× digital zoom, a 50 Hz refresh rate, and a 7.5° × 5.7° field of view. Available thermal palettes include Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, and Green Monochrome.

The digital module features a 1/1.8" CMOS sensor with a resolution of 3840 × 2160 px (4K UHD) and a 60 mm F2.2 lens. It provides 5.5× optical magnification and 4× digital zoom. An interchangeable LED IR illuminator is provided for observation in the dark – the 940 nm module is fitted as standard, while an 850 nm version is also included. The detection range reaches up to 350 m with the 940 nm illuminator and 400 m with the 850 nm illuminator. The optical module offers Day, Night, Auto, Green, and Yellow modes.

Images from both modules are displayed on a 0.49" OLED display with a resolution of 1920 × 1080 px. EIS electronic image stabilisation operates from 2× magnification and is complemented by Zoom Pro, HSIS, and Sync Pro technologies. A practical control ring enables quick switching between the thermal and digital modules, while the focusing controls are positioned closer to the eyes for easier one-handed operation.

The integrated laser rangefinder measures distances of up to 1,000 m with an accuracy of ±1 m and also supports horizontal distance measurement. The ballistic calculator uses the measured distance to calculate correction values for a riflescope. A digital compass and GPS are also included.

The binoculars support photo and video recording, including audio, with 64 GB of built-in memory available for storage. GPS also allows location data to be recorded. Other features include Wi-Fi connectivity and compatibility with the HIKMICRO Sight app, PIP mode, hot spot tracking, and an automatic sleep mode.

The durable construction with non-slip rubberised side panels meets the IP67 protection rating and is designed to operate at temperatures from -30 to 55 °C. Power is supplied by two 18650 Li-ion batteries, providing up to 6.5 hours of operation, while a total of four rechargeable batteries and a charger are included in the package. The device weighs 900 g without batteries, measures 143 × 75 × 223 mm, and can also be mounted on a tripod using the supplied adapter.

The device is covered by a 3-year manufacturer's warranty.

Important: The stated detection ranges are based on the manufacturer's data under optimal conditions; the actual range may vary depending on the weather, the size of the observed object, and ambient lighting conditions.

Features of the HABROK 4K HH35L 2.0 Multispectral Binoculars by HIKMICRO

• Thermal imaging module
  • Thermal sensor: Uncooled VOx 384 × 288 px, 12 μm
  • Thermal sensitivity: < 15 mK
  • Refresh rate: 50 Hz
  • Lens: 35 mm F1.0
  • Detection range: Up to 1,800 m
  • Magnification: 4× optical, 5× digital
  • Field of view: 7.5° × 5.7°
  • Minimum focusing distance: 5 m
• Digital module
  • Sensor: 1/1.8" CMOS 3840 × 2160 px
  • Lens: 60 mm F2.2
  • Optical magnification: 5.5×
  • Digital zoom: 4×
  • Field of view: 7.3° × 4.1°
  • Minimum working distance: 8 m
  • Interchangeable LED IR illuminator: 940 / 850 nm
  • Night detection range: Up to 350 m at 940 nm / 400 m at 850 nm
  • Modes: Day, Night, Auto, Green, Yellow
• Display: 0.49" OLED 1920 × 1080 px
• Exit pupil: 8 mm
• Eye relief: 15 mm
• Dioptre adjustment: -5D to +3D
• Interpupillary distance: 60–74 mm
• Laser rangefinder: Up to 1,000 m, accuracy ±1 m, Class 1 laser
• Ballistic calculator
• EIS, Zoom Pro, HSIS, and Sync Pro functions
• GPS and digital compass
• PIP and hot spot tracking
• Wi-Fi and HIKMICRO Sight app
• Photo, video, and audio recording
• Built-in memory: 64 GB
• Automatic sleep mode
• Power supply: 2× 18650 Li-ion batteries
• Battery life: Up to 6.5 hours
• USB-C: 5 V / 2 A
• Protection rating: IP67
• Operating temperature: -30 to 55 °C
• Dimensions: 143 × 75 × 223 mm
• Weight: 900 g without batteries
• Manufacturer's warranty: 3 years

Package Contents:

• HABROK 4K HH35L 2.0 multispectral binoculars
• Interchangeable 940 / 850 nm LED IR illuminators
• Rechargeable 18650 batteries (4 pcs)
• Battery charger
• Binocular carrying case (HM-BINO HARNESS-H)
• Neck strap
• Tripod adapter
• USB-C cable
• Lens cloth
• Manual in Czech and Slovak
